A front mounting bracket is installed on the front of the vehicle. With the snow roller brush (required during snow cleaning operation) installed, front overhang:1937mm, total vehicle length: 10047mm; Side protection: Q235A, bolt connection; Rear protection: Q235B, bolt connection, section size: 160X50mm, ground clearance: 540mm. Equipped with a satellite positioning driving recorder; ABS model: 4460046300; ABS manufacturers: WABCO Vehicle Control Systems (China) Co., Ltd.
Specifications
| Name | DD5160TCXZE Snowplow |
| Size: L?x?W?x?H（mm） | 10047,8110x2500x2905 |
| Cargo compartment dimension(mm) | - |
| G.V.W.(kg)（kg） | 16000 |
| Curb mass(kg) | 9000 |
| Rated loadkg) | 6870 |
| Wheel base（mm） | 4700 |
| Number of axles | 2 |
| ABS | have |
| Approaching angle/ departure angle | 13.5/12 |
| Front?&?rear?overhang(mm) | 1370/2040 |
| Maximum?speed（km/h） | 82 |
| Tire?number | 4 |
| The specification of tires | 11.00-20,11.00R20,12,00-20,12.00R20 18PR |
| Front track | 2035 |
| Rear track | 1850 |
| Oil consumption rate(L/100Km) | - |
| Emission standard | - |
